180W Portable Folding Xplorer Solar Panel kit with Charge Controller

This 180W Xplorer folding Portable solar kit includes all you need for charging 12V battery:

• High efficiency 90W + 90W folding solar panels
• Advanced fully automated 20A pwm solar charge controller with many protection functions
• Adjustable aluminium stand, handle and latches
• 2.5m cable with a battery plug, Anderson connection and a fuse
• Battery crocodile clips for ease of connection
• Protective case
• Installation manual

The kit has several important features which make it a truly unique premium quality product:

• High efficiency 180W folding monocrystalline solar panels are made of high quality solar cells
• Storage bag is not just a dust cover – it’s a protective case made with a layer of foam which can prevent accidental damages to the frame and glass
• Advanced fully automated 20A solar charge controller provides complete overcharge, reverse current, incorrect polarity and short circuit protection
• The controller uses PWM technology and supports several battery types with different charging parameters for maximum efficiency of charging
• The kit is very easy to set up and install, you can start using it in seconds.

Solar panel specifications:

• Peak power: 180W
• Maximum power current: 8.6A
• Open circuit voltage: 24.5V
• Short circuit current: 9.04A
• Power allowance range: +/- 3%
• Support stand to angle towards direct sunlight for max generation
• Anderson power disconnect plug
• 20a fused battery power cable protection
• Crocodile battery connection clips
• Weight 8.3kg
• Dimensions :  When folded out and in use  1193mm long x 825mm Wide
• Dimensions :  When folded in  825mm long x 595mm Wide

• All charging parameters are adjustable
• Built in short circuit protection, open circuit protection, reverse protection, overload protection.
• Dual MOSFET reverse current protection, low heat production.
• Full four-stage PWM charge management
• Built in industrial microcontroller
