12V 90Ah fit-and-forget AGM lead-acid battery for leisure,marine & many other deep cycle applications – from Expedition’s exclusive battery range
Features
• Absorbed Glass Mat technology (great durability and vibration-resistance)
• Totally sealed for life – dry-cell, unspillable and safe
• Maintenance-free
• Minimal self-discharge – ideal for seasonal use
• Specifically designed for cyclic use over sustained periods of time (deep-cycle)
• Typical max. cycle life of 700 cycles @ 50% Depth of Discharge (DoD)*
• Power demand level of intended application: Medium (casual to regular usage)
• 99.99% pure primary lead (PPL) for faster charging, better performance & a cleaner environment
M6 Screw down bolt fixings supplied. If you require round posts (car type) these can be supplied. Please see our accessories section.
Technology Low-Down
Absorbed Glass Mat (AGM) batteries are dry-cell, with the battery acid being encapsulated in fibreglass sheets. In comparison to flooded batteries, AGMs offer increased levels of reliability and versatility – with no free acid, they can be mounted in any orientation and are better able to handle vibration.
Replaces Part numbers: LAGM85, LSLC12-75, LSLC12-85, NP75-12, YPC75-12, UB12750, REC80-12, PAGM75-12, UL75-12, EV12-75, PS12750, RS727-0439, 6-evf-80, 6fm75te, Rolls S12-95AGM, R12-90AGM
Please ensure your charging method can accommodate AGM batteries as charging at non-AGM charge settings can adversely affect the life of the battery. Why not read our AGM battery guide here or call us on 01706356356.
*The suggested number of lifetime cycles & capacity is an indication based on manufacturer laboratory test conditions . The amount of useable energy and cycle life will vary due to multi applicational factors, usage pattern, discharge times,charging, maintenance and climatic conditions . A battery can deliver only a fixed amount of Energy and capacity over its life which will occur over different periods of time depending on the application and conditions.

| Height (mm) | 214 |
|---|---|
| Length (mm) | 258 |
| Width (mm) | 168 |
| 100 Hour | 90 |
| 20 Hour | 80 |
| Brand | Expedition |
| Capacity (Ah) | 90 |
| Construction | AGM |
| Ideal Charge Voltage | 14.4V -14.8V |
| Maintenance Free | Yes |
| Product Type | Battery |
| Recharge Cycles | 600 |
| Suitable for wild camping? | Yes |
| Terminal Layout | Positive on Left (Layout 1) |
| Terminal Type | Bolt Through Terminals (Type 2) |
| Top Up Charge Voltage | 13.5V -13.8V |
| Voltage | 12V |
| Warranty (Years) | 4 |
| Weight (kg) | 22 |
