120W Xplorer Monocrystalline Cell Solar Panel Kit With 10A PWM Controller

Full Kit with plastic corner fixing brackets ,10a PWM charge controller  and 5m of cable with MC4 conenctions supplied

This highly efficient solar Cell 120w all black solar panel is ideal for Caravans, Boats, Motorhomes, Campers, sheds and many more applications.

Harness the power from the sun to provide the power you need on the move. Ideal for charging 12v batteries and directly powering 12v devices and appliances

The long-lasting, high-efficiency monocrystalline solar cell and the tough, sealed, aluminium frame will give you years and years of consistent, free power. Waterproof design ensures the panel can be used in all weather conditions.

This kit comes with everything you need to get going. All the leads, fixing brackets and solar charge controller to prevent overcharging your batteries.

Specification

Peak power: 120 W

Nominal voltage: 19.1V

Maximum power current: 6.2A

Open circuit voltage (VOC): 22.3V

Short circuit current:6.6A

Power allowance range:+/- 3%

Dimensions: 580 x 1070 x 30 mm

Weight:6.9 kg

4 mounting holes 9 x 11 mm

5 Metre Cable attached- Can be cut to length upon your installation

Mc4 connections

10A 12V/24V Xplorer  PWM quality Charge Controller supplied

Cable entry gland Supplied

Additional Side Reinforcing brackets Supplied

Fuses, adhesive & battery terminals Not Supplied

5 Year Warranty Solar cells are guaranteed to produce at least 90% of nominal power in 10 years and 80% of nominal power in 25 years
